T-Block, Tile Roof Solar PV Mounting Accessories
T-Block, Tile Roof Solar PV Mounting Accessories

T-Block, Tile Roof Solar PV Mounting Accessories

T-block is a key accessory for solar photovoltaic mounting on tile roofs. It plays a vital role in the installation process of photovoltaic brackets. The T-shaped block has an ingenious design and a stable structure, which can effectively fix the connection between the photovoltaic bracket and the ground, thus improving the stability of the entire bracket system. This stability ensures that the photovoltaic bracket can firmly support the solar panels under severe weather conditions such as strong winds and heavy rains, preventing them from being overturned or damaged by external forces. In tile roof photovoltaic projects, T-shaped blocks are particularly widely used. It can not only adapt to tiles of different shapes and sizes but also ensure a tight connection between the bracket and the tile roof, avoiding safety hazards caused by loose or displaced brackets. The T-shaped block also features easy installation and high durability. It is usually made of high-strength, corrosion-resistant materials. If you need to mount one solar panel onto your tin roof flexibly and without too much bothering of so many long rails and accessories, here we bring you a convenient solar mounting bracket kit for mounting solar panels onto sloped pitched tin roofs or flat tin roofs. If you need to mount more solar panels, please add the kit quantities as you like. · 1)Rail*4pcs: 76cm/29.9 inch long, supporting one or two solar panels fixed vertically. · 2)L foot*4pcs: flexibly secure rails to the roof at the desired height of 33-68mm. · 3)Adjustable end clamps*4pcs: secure a solar panel 30-45mm/1.18 inch-1.77 inch thick · 4)Adjustable mid clamps*2 secure two solar panels 30-45mm/1.18 inch-1.77 inch thick in the middle · 5) Self-tapping screw*4pcs, wood screw*4pcs: please choose the self-tapping screw for steel beams or wood screw for wood beams. · 6)L spanner*1pc: a tool to tighten or loosen end clamps and mid clamps.· 7) rail splice*2pcs: to extend rail length.
Get A Quote
PREV：No previous articleNEXT：T-Block, Tile Roof Solar PV Mounting Accessories
  • Parameter
  • Contact Us
  • Model CMCP-002 Material AL-6005T5
    Surface Treatment anodizing Weight 73.6g


    Rail Installation: Install the mounting rails onto the roof brackets. These rails provide the framework for attaching the solar panels. Secure the rails to the brackets using the provided hardware.

    Panel Mounting: Once the rails are in place, mount the solar panels onto the rails. This may involve sliding the panels into the rail channels or using additional hardware provided by the manufacturer.

    Secure Connections: Double-check all connections, ensuring that the roof brackets, rails, and solar panels are securely fastened.

    System Testing: Conduct a thorough system test to verify the proper functioning of the solar panel installation. This includes checking electrical connections, monitoring power output, and ensuring all safety measures are in place.

    It includes:

    1.Rail*4pcs

    2. L foot*4pcs

    3. Adjustable end clamps*4pcs

    4. Adjustable mid clamps*2

    5. Self-tapping screw*4pcs, wood screw*4pcs

    6. L spanner*1pc

    7. rail splice*2pcs

    Adjustable End Clamp

    · Hold the edge of the solar panel tight and flexibly, fit 30 mm - 45 mm thick solar panels

    Universal Use for Tin Roofs

    · Hold the rails on tin roofs flexibly, support rails at your desired height, ranging from 33-68 mm high, and provide a height to allow proper airflow between the panel and the roof surface, assuring your panel stays cool in high temperatures.

    · Universal use for tin roofs

Related Products

About Us
Jiangsu Aozheng Metal Products Co., Ltd.

Jiangsu Aozheng Metal Products Co., Ltd. Is China T-Block, Tile Roof Solar PV Mounting Accessories Suppliers and Wholesale T-Block, Tile Roof Solar PV Mounting Accessories Factory, We are a combination of industry and trade enterprises, is committed to the production of stainless steel, aluminum alloy, carbon steel and low alloy steel materials, architectural hardware, the use of advanced automated cutting, stamping, welding process, is a diversified and large-scale professional production base, raw materials molding and machining plant in one, based on high quality and high-end market, the annual production of various types of building materials 2000 tons, mainly exported to the United States, Germany, Italy, Britain, South Korea, Australia, Canada, the Middle East and dozens of countries, with customers including large construction companies, including well-known construction team, has become their building materials in the Middle East. With an annual production of more than 2000 tons of various building materials, mainly exported to dozens of countries such as the United States, Germany, Italy, the United Kingdom, South Korea, Australia, Canada, the Middle East, etc., and cooperating with large-scale construction companies, including the world's high-quality architectural team, we have become an important supplier of their building materials in China.

Certificate Of Honor
  • High-Tech Enterprises
  • Made in China Network Certification
  • Business License
  • Opening Permit
  • Jiangsu Private Science & Technology Enterprise
  • A heavy-duty combined stone pendant
  • An integrated stone back bolt
News
Message Feedback
Aluminum Photovoltaic Bracket Rails &Accessories Industry knowledge

Why is aluminum widely used in photovoltaic brackets? What properties does it have that make it suitable for this application?

Aluminum is widely used in photovoltaic brackets mainly because it has the following key properties:

Lightweight: Aluminum has a low density and is lighter than steel, which makes aluminum photovoltaic brackets easier to handle and install than steel brackets. Lighter materials also help reduce shipping costs and installation time.

Corrosion Resistance: Aluminum is naturally highly resistant to corrosion, which means it is better able to resist corrosion in harsh environmental conditions, such as high humidity or marine environments. This feature can significantly improve the service life and reliability of photovoltaic brackets.

Strength and Stiffness: Although aluminum is lightweight, it is still strong and stiff enough to support photovoltaic panels and resist external stresses such as wind loads, snow loads, etc. This makes the aluminum photovoltaic bracket very good in terms of structural stability and safety.

Processability: Aluminum is easy to process and shape, and can be processed into different shapes and sizes by extrusion, cutting, drilling, etc. This allows aluminum photovoltaic brackets to be customized according to specific needs and adapted to various installation environments and photovoltaic system designs.

Durability: Aluminum has good durability and anti-aging properties and can withstand long-term UV exposure and climate change, maintaining its structural strength and appearance.

Recyclability: Aluminum is a highly recyclable material and is environmentally friendly. The energy consumption of recycling aluminum is much lower than that of the production process of raw aluminum, which makes aluminum also has advantages in terms of environmental protection.

What are the common types of aluminum photovoltaic brackets? What different photovoltaic systems are they suitable for?

Common types of aluminum photovoltaic brackets include:
Fixed brackets:
Features: These brackets are fixed at an angle to support the photovoltaic panel to maintain a constant tilt angle.
Applicable systems: Suitable for residential and commercial photovoltaic systems, especially in areas where light conditions are relatively stable.

Adjustable brackets:
Features: This type of bracket allows the tilt angle of the photovoltaic panel to be adjusted to optimize light reception.
Applicable systems: Suitable for systems that need to adjust the light angle according to the season or time, such as large commercial or agricultural photovoltaic systems.

Tracking brackets:
Features: Tracking brackets can automatically adjust the angle of the photovoltaic panel as the sun moves to maximize energy collection.
Applicable systems: Suitable for photovoltaic systems with high efficiency requirements, such as large solar power plants.

Roof brackets:
Features: Designed for installation on building roofs, usually containing fixings compatible with roofing materials.
Applicable systems: Suitable for photovoltaic systems for residential and small commercial buildings.

Ground brackets:
Features: Used to mount photovoltaic panels on the ground, usually fixed by concrete foundations or ground piles.
Applicable systems: Applicable to large-scale ground photovoltaic systems, such as large solar power plants.

Bifacial bracket:
Features: Designed to support bifacial photovoltaic panels, which can collect sunlight from both sides of the photovoltaic panels.
Applicable systems: Applicable to systems that need to maximize the energy collection of photovoltaic panels, usually used in high-efficiency application scenarios.

Integrated bracket:
Features: Integrate the bracket and photovoltaic panel into one system to simplify the installation process.
Applicable systems: Applicable to systems that require quick installation or high aesthetic requirements.
