Size | Hose type | Screw length | d(mm) | L(mm) | l(mm) | Ultimate tension (kgf) | Ultimate shear (kgf) |
M8*110 | RIM-8 | 110 | 10 | 80 | 13 | 2417 | 1571 |
M10*130 | RI[-10 | 130 | 12 | 90 | 20 | 3600 | 2489 |
M12*160 | RI[-12 | 160 | 14 | 110 | 25 | 5905 | 3611 |
M14*180 | RIM-14 | 180 | 16 | 115 | 30 | 6140 | 4896 |
M16*190 | RI[-16 | 190 | 18 | 125 | 35 | 7232 | 6722 |
M18*200 | RIM-18 | 200 | 22 | 150 | 40 | 9700 | 7109 |
M20*260 | RIM-20 | 260 | 25 | 170 | 65 | 13372 | 10496 |
M22*280 | RIM[-22 | 280 | 25 | 190 | 65 | 14800 | 10516 |
M24*300 | RIM[-24 | 300 | 28 | 210 | 65 | 18952 | 10771 |
M30*380 | RIM-30 | 380 | 35 | 280 | 65 | 25051 | 17850 |
Model | Screw diameter (mm) | Screw total length L (mm) | Drilling diameter DB (mm) | Burial depth T(mm) | Fixture thickness Smax (mm) | Minimum substrate thickness D (mm) | Maximum tightening torque Mp (Nm) |
M8 | M8 | 110 | 10 | 80 | 14 | 130 | 10 |
M10 | M10 | 130 | 12 | 90 | 20 | 140 | 20 |
M12 | M12 | 160 | 14 | 110 | 25 | 160 | 40 |
M16 | M16 | 190 | 18 | 125 | 35 | 175 | 80 |
M20 | M20 | 260 | 25 | 170 | 65 | 220 | 150 |
M24 | M24 | 300 | 28 | 210 | 65 | 260 | 200 |
M30 | M30 | 380 | 35 | 280 | 70 | 330 | 400 |
Anchor Bolts
There are many types of expansion bolts available for use to fix anchors onto different types of walls. Expansion bolts are all tested to meet the pull-out force and shear force performance criteria.
Jiangsu Aozheng Metal Products Co., Ltd. Is China Chemical Anchor Suppliers and Wholesale Chemical Anchor Factory, We are a combination of industry and trade enterprises, is committed to the production of stainless steel, aluminum alloy, carbon steel and low alloy steel materials, architectural hardware, the use of advanced automated cutting, stamping, welding process, is a diversified and large-scale professional production base, raw materials molding and machining plant in one, based on high quality and high-end market, the annual production of various types of building materials 2000 tons, mainly exported to the United States, Germany, Italy, Britain, South Korea, Australia, Canada, the Middle East and dozens of countries, with customers including large construction companies, including well-known construction team, has become their building materials in the Middle East. With an annual production of more than 2000 tons of various building materials, mainly exported to dozens of countries such as the United States, Germany, Italy, the United Kingdom, South Korea, Australia, Canada, the Middle East, etc., and cooperating with large-scale construction companies, including the world's high-quality architectural team, we have become an important supplier of their building materials in China.
Jiangsu Aozheng Metal Products Co., Ltd. plays a significant role in the manufacturing of various materials, including stainless steel, aluminum alloys, carbon steel, and architectural hardware. Their...
READ MOREThe mounting brackets for solar panels are a very important part of the solar power generation system. They are mainly used to fix the solar panels and ensure that the panels can be stably installed o...
READ MOREIn the context of electrical or cable installation, a cast-in channel installation typically refers to a method of embedding metal channels (usually made of steel or aluminum) into concrete or masonry...
READ MOREIn the field of modern construction, every detail carries the heavy responsibility of safety and stability, and chemical anchor bolts, as an indispensable fastening element in this huge system, are silently guarding the foundation of every building with their unique performance and wide range of applications. Jiangsu Aozheng Metal Products Co., Ltd., with its profound industry accumulation and technological innovation, is leading the chemical anchor bolt industry to develop in a higher quality and more professional direction.
Chemical anchor bolts are fasteners that achieve anchoring through chemical reactions. It uses special chemical adhesives to fix the screw in substrates such as concrete and rock to form a solid anchoring system. This process involves physical penetration and chemical bonding between the adhesive and the substrate, and ultimately achieves a high-strength and durable anchoring effect. Compared with traditional mechanical anchor bolts, chemical anchor bolts have significant advantages such as convenient construction, strong adaptability, and reliable anchoring force.
Jiangsu Aozheng Metal Products Co., Ltd. is well aware that high-quality materials and exquisite craftsmanship are the cornerstones of creating high-quality chemical anchor bolts. The company selects a variety of materials such as stainless steel, aluminum alloy, carbon steel, and low-alloy steel to meet the use needs in different environments. In terms of production technology, the company has introduced advanced automated cutting, stamping, welding and other equipment to ensure that each product can achieve precise size and perfect appearance. At the same time, the company has also established a complete quality management system. From raw material procurement to finished product delivery, each process has undergone strict quality inspection to ensure the stability and reliability of the product.
The application field of chemical anchors is extremely wide, covering almost all construction projects that require structural reinforcement and connection. In the construction of large-scale infrastructure such as high-rise buildings, bridges, tunnels, subways, etc., chemical anchors have become an indispensable key component due to their excellent anchoring performance. Chemical anchors also play an important role in curtain wall installation, mechanical equipment fixing, pipeline support and hanger installation and other fields. Jiangsu Aozheng Metal Products Co., Ltd. has successfully served many large-scale construction projects at home and abroad with its rich product line and professional technical support, and has won wide praise from customers.
In the future, Jiangsu Aozheng Metal Products Co., Ltd. will continue to adhere to the business philosophy of "quality first, customer first", continuously increase R&D investment, and promote technological innovation and product upgrades. The company will actively explore the application of new materials and new processes in the field of chemical anchors, and strive to improve the comprehensive performance and added value of products. At the same time, the company will further optimize the international market layout, strengthen communication and cooperation with global customers, and jointly promote the healthy development of the chemical anchor industry. In the future, Jiangsu Aozheng Metal Products Co., Ltd. will work with colleagues from all walks of life to jointly write a new chapter in the stability of buildings.
